Procesor INTEL Core i7 6700 (6. generacija, 3.4 GHz)

Processor special features
Intel® InTru™ 3D Technology: Yes
Intel Software Guard Extensions (Intel SGX): Yes
Intel® Boot Guard: Yes
Enhanced Intel SpeedStep Technology: Yes
Intel TSX-NI: Yes
Intel® Clear Video HD Technology (Intel® CVT HD): Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel® Insider™: Yes
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Intel TSX-NI version: 1.00
Intel® vPro™ Platform Eligibility: Yes
Intel Stable Image Platform Program (SIPP) version: 1.00
Intel Identity Protection Technology version: 1.00
Intel® Wireless Display (Intel® WiDi): Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID): Yes
Intel Enhanced Halt State: Yes
Intel® Memory Protection Extensions (Intel® MPX): Yes
Intel® Optane™ Memory Ready: No
Intel® Transactional Synchronization Extensions: Yes
Intel Secure Key Technology version: 1.00
Conflict-Free processor: Yes
Intel Trusted Execution Technology: Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel Virtualization Technology (VT-x): Yes
Intel® OS Guard: Yes
Intel® Turbo Boost Technology: 2.0
Intel VT-x with Extended Page Tables (EPT): Yes
Intel 64: Yes
Intel® Secure Key: Yes
Intel® Identity Protection Technology (Intel® IPT): Yes
Intel® Quick Sync Video Technology: Yes
Intel Clear Video Technology: Yes
Intel® Turbo Boost Technology 2.0 frequency: 4 GHz
Intel® Small Business Advantage (Intel® SBA): Yes
Intel Stable Image Platform Program (SIPP): Yes
Intel Small Business Advantage (SBA) version: 1.00
Other features
Maximum internal memory: 64 GB
Graphics output: eDP/DP/HDMI/DVI
Video decoding: Yes
Maximum internal memory: 65536 MB
Memory
ECC: No
Memory types supported by processor: DDR3L-SDRAM
Maximum internal memory supported by processor: 64 GB
Memory voltage supported by processor: 1.35 V
Memory types supported by processor: DDR4-SDRAM
Memory channels: Dual-channel
Memory clock speeds supported by processor: 2133 MHz
Memory clock speeds supported by processor: 1333 MHz
Memory clock speeds supported by processor: 1600 MHz
Memory clock speeds supported by processor: 1866
Packaging data
Package type: Retail box
Operational conditions
Tcase: 71 °C
Graphics
On-board graphics card outputs supported: DisplayPort
On-board graphics card: Yes
On-board graphics card outputs supported: Embedded DisplayPort (eDP)
On-board graphics card refresh rate at maximum resolution (HDMI): 24 Hz
On-board graphics card OpenGL version: 4.5
On-board graphics card DirectX version: 12.0
On-board graphics card maximum resolution (DisplayPort): 4096 x 2304 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel): 4096 x 2304 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
On-board graphics card maximum resolution (HDMI): 4096 x 2304 pixels
On-board graphics card outputs supported: DVI
On-board graphics card outputs supported: HDMI
On-board graphics card ID: 0x1912
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 60 Hz
Maximum on-board graphics card memory: 64 GB
On-board graphics card model: Intel® HD Graphics 530
On-board graphics card 4K support: Yes
On-board graphics card dynamic frequency (max): 1150 MHz
Number of displays supported (on-board graphics): 3
On-board graphics card base frequency: 350 MHz
Processor
Thermal Design Power (TDP): 65 W
Processor socket: LGA 1151 (Socket H4)
Processor lithography: 14 nm
System bus rate: 8 GT/s
Processor boost frequency: 4 GHz
Processor ARK ID: 88196
Processor generation: 6th gen Intel® Core™ i7
Processor base frequency: 3.4 GHz
Processor cache type: Smart Cache
Bus type: DMI3
Compatible chipsets: Intel® Q170
Processor manufacturer: Intel
Processor threads: 8
Compatible chipsets: Intel® Z170
Component for: PC
Processor codename: Skylake
Processor cores: 4
Processor operating modes: 64-bit
Stepping: R0
Compatible chipsets: Intel® B150
Processor family: Intel® Core™ i7
Generation: 6th Generation
Processor code: SR2L2
Cooler included: No
Processor model: i7-6700
Box: No
Compatible chipsets: Intel® H170
Compatible chipsets: Intel Q150
Memory bandwidth supported by processor (max): 34.1 GB/s
Processor series: Intel Core i7-6700 Desktop series
Compatible chipsets: Intel® H110
Processor cache: 8 MB
Features
Thermal solution specification: PCG 2015C
PCI Express configurations: 2x8
CPU configuration (max): 1
Market segment: Desktop
Commodity Classification Automated Tracking System (CCATS): G077159
Idle States: Yes
Execute Disable Bit: Yes
PCI Express configurations: 1x8+2x4
PCI Express slots version: 3.0
Thermal Monitoring Technologies: Yes
Embedded options available: Yes
PCI Express CEM revision: 3.0
Graphics & IMC lithography: 14 nm
Maximum number of PCI Express lanes: 16
PCI Express configurations: 1x16
Supported instruction sets: SSE4.1
Export Control Classification Number (ECCN): 5A992C
Supported instruction sets: AVX 2.0
Supported instruction sets: SSE4.2
Scalability: 1S
Technical details
Servicing status: End of Servicing Lifetime
End of servicing updates date: Friday, September 30, 2022
Product family: 6th Generation Intel Core i7 Processors
Launch date: Q3'15
Supported memory types: DDR3L-SDRAM
Supported memory types: DDR4-SDRAM
Maximum resolution & refresh rate (HDMI): 4096x2304@24Hz
Status: Launched
Bus type units: GT/s
Maximum resolution & refresh rate (DisplayPort): 4096x2304@60Hz
Processor ID: 0x1912
Maximum resolution & refresh rate (Integrated Flat Panel): 4096x2304@60Hz
Number of graphics cores: 2
Maximum resolution & refresh rate (VGA): N/A
Maximum memory: 64 GB
Last change: 63903513
Product type: Processor
Bus bandwidth: 8
Maximum graphics card memory: 64 GB
Bus speed: 8 GT/s
Processor cache: 8192 KB
Processor brand name: Intel Core i7
Intel Core i7 Processor
Maximum resolution (WiDi): 1080p
Logistics data
Harmonized System (HS) code: 85423119
Weight & dimensions
Processor package size: 37.5 x 37.5 mm
