Integrirano pojačalo DENON PMA-1700NE
Integrirano pojačalo DENON PMA-1700NE
1.799,00 €
Najčešće dostupno
Ronis Čakovec - Galerija sjever
Ronis Zagreb - Velesajam
Ronis Varaždin - skladište
Ronis Zagreb - Velesajam
Očekivana isporuka do 19.08.2026.
Točniju potvrdu roka i dostupnost javit ćemo ubrzo po narudžbi.
Informacije o raspoloživosti i vremenu isporuke su indikativne, ažuriraju se u intervalima i podložne su promjenama, te ne čine obvezujuću ponudu. Potvrdu dostupnosti i cijene ćemo vam dostaviti nakon što primimo i obradimo vašu narudžbu. Ugovor o kupnji je sklopljen tek po izdavanju računa.
PMA-1700NE - S naprednim visokostrujnim jednostrukim push-pull strujnim krugom, naprednim AL32 Processingom, kao i MM/MC phono equalizerom, Denon PMA-1700NE pruža izvanrednu kvalitetu zvuka s preciznim detaljima.
Šifra: 76184
EAN: 747192137618
Više o proizvodu
Jamstvo
24 mjeseci
Specifikacije
Mocan zvuk iz integriranog pojacala: Projektirano s vrhunskom Denon tehnologijom, ovo pojacalo pokrece dva kanala na 140 W.
Vjerna reprodukcija zvuka: Napredni AL32 Processing Plus donosi bogat zvuk prepun detalja – upravo onako kako je i zamišljeno.
Ocuvanje integriteta s odabranim komponentama izrade: S preko 110 godina audio izvrsnosti, Denon proizvodi napravljeni su da traju.
Integrirano pojacalo velike snage od 140 W: Povežite svoje zvucnike sa 140 W snage po kanalu na 4 Ohma. Ovo integrirano pojacalo nudi kompatibilnost s najširim rasponom od 6 vrsta zvucnika i impendancijom za stabilnost rada.
Napredni AL32 Processing Plus: Napredni AL32 Processing Plus podržava audio izvore visoke rezolucije – 384 kHz/32-bit.
USB-DAC: Za preciznu sinkronizaciju digitalnih sklopova, PMA-1700NE pruža USB-DAC funkcije koje podržavaju visoku rezoluciju – do 11.2 MHz DSD i 384 kHz/32-bit PCM ulazne signale. Izraden iznimno kvalitetno, DAC potiskuje podrhtavanja i osigurava optimalnu preciznost u D/A pretvorbi.
Izuzetno precizne elektronske kontrole: PMA-1700NE ima elektronske kontrole glasnoce, balansa i tona – ali za sve pruža analogni osjecaj mijenjanja. Univerzalni mehanizam nudi glatko i ujednaceno podešavanje navedenih funkcija.
Specifikacije
General
Unit (W x D x H)434 x 410 x 135mm
17.1 x 16.1 x 5.3in
Cabinet Size (W x D x H)434 x 374 x 135mm
17.1 x 14.7 x 5.3in
Net weight17.6kg
38.8lb
Packaging Dimensions (W x D x H)548 x 520 x 249mm
21.6 x 20.5 x 9.8in
Packaging gross weight20.4kg
45lb
Carton Color2 Color
Cushion / Packing4 Separate / Sheet
Panel ColorSP / BK
Front (Center) PanelAluminum
Side coverSECC with 4 straight emboss
Side screwSP: Nickel / BK: Black
Rear PanelSECC t1.0mm
Chassis MaterialSECC t1.2mm
Bottom LayerSingle
Volume KnobAluminum
Input SelectorAluminum
Bass/Treble/Balance/ Phono Sel knobsAluminum
Power buttonAluminum
Other knob/button (LOUDNESS, SOURCE DIRECT etc)Mold (Source Direct,Analog Mode,MM/MC)
FootABS resin with rigid rib
w/Hot stamp
(H : 20mm)
Heatsink for Power AmplifierExtruded Aluminum
Specifications
Rated Output Power70W + 70W
(8ohm,20Hz-20kHz,THD0.07%)
140W + 140W
(4ohm, 1kHz, THD0.7%)
Speaker ImpedanceA or B : 4 ~ 16ohm
A + B : 8 ~ 16ohm
Frequency Response5Hz - 100kHz (0~ -3dB)
Total Harmonic Distortion0.01 % (Rated output: –3 dB),
8 ohm/ohms, 1 kHz
Dumping Factor100 and over
Input Sensitivity: Phono inputMM: 2.5 mV / 47 kohm
MC: 200
RIAA Deviation20 Hz - 20 kHz ±0.5 dB (MM/MC)
Phono Maximum InputMM : 130mV / 1kHz
MC : 10mV / 1kHz
Input Sensitivity: CD/LINE/RECORDER125 mV / 19 kohm
Input Sensitivity: Power Amp input0.85V / 47kohm (EXT. PRE)
Signal to Noise RatioPHONO (MM): (89dB)
PHONO (MC): (74dB)
CD: (107dB)
Tone ControlBASS : 100Hz ±8dB
TREBLE : 10kHz ±8dB
Power Consumption295W
at Standby0.2W TV autoplay off
0.4W TV autoplay on
Audio Feature
Power Amplifier CircuitNew UHC-MOS
Single Push Pull (7)
Power TransDual El Core
Pre Amplifier CircuitVariable Gain Preamplifier
(OP AMP)
VolumeElectric
(MUSES 72323)
Bass / Treble / Mid / Balance ControlYes / Yes / No / Yes
Type of Tone ControlElectric
Controlled by Potentiometer
Headphone CircuitUse Poweramplifier
Source DirectYes
Analog Amp ModeYes (button on front panel)
Other70
DAC CircuitPCM1795
Digital FilterFixed
Digital ProcessingAdvanced AL32 Processing Plus
DAC Master Clock Design (Not Support Network Playback)Yes
Asyncronous mode (for USB-B input)yes
Isolator (for USB-B input)Yes
Full Isolation
Connectivity
Phono InputYes (MM / MC)
*default=MM
Analog Input (include Phono) / REC Out (RCA)4/1
(PHONO / CD / NETWORK ,AUX/ RECORDER)
Optical input / output (Maximum Support)2 / 0 (192kHz/24bit)
Coaxial input / output (Maximum Support)1 / 0 (192kHz/24bit)
Ext. Pre Input (Power Amp Direct)Yes(Ext.Pre)
2 sets of Speaker OutputYes (Bi-wiring)
Speaker TerminalGold Plated
Headphone Output1
(Turn off the speaker when inserting headphone)
Remote Control Bus TerminalYes (mini)
AC InletYes
Wi-FiNo
HEOSNo
USB B (USB DAC)1 (Rear)
Module or Main DeviceNew XMOS
(XU210-256-TQ128 )
PCM Sample Rate~384kHz/32bit
DSD Audio Streaming (DoP)~11.2MHz
Roon CertificatonYes(Roon Tested)
TBD
Control
Remote ControllerSystem Remote
(w/CD Player Control)
Unit control (Button)Push Switch: 1
POWER
Tact Switch : 3
ANALOG MODE, SOURCE DIRECT, MM / MC
Unit control (Knob)5
VOLUME, INPUT SELECTOR, BASS, TREBLE, BALANCE
LEDPOWER: 1 Red / Green
ANALOG MODE: 1 Green
SOURCE DIRECT: 1 Green
MM / MC :1 Green
Front Panel DisplayYes
(OLED 128 x 100 dot)
MXS4036-A
Display LanguageAlphabetical
Dimmer for Front DisplayBright / Dim / Dark / Off
Control with App via Network Player (Use Remote Control Bus)Yes
TV Auto-play (Opt/Coax digital-in detecter)Yes
Last Function MemoryYes
Auto Standby ModeYes
Owner's ManualWeb Manual
E2: (English, German, French, Italian, Dutch, Spanish,
Swedish, Polish, Russian)
E3: (English, French, Spanish)
E1C: (Simplified Chinese)
JP: (Japanese)
Paper
JP: (Japanese)
Quick Start GuidePaper
E2: (English, German, French, Italian, Dutch, Spanish,
Swedish, Polish, Russian)
E3: (English, French, Spanish)
E1C: (Simplified Chinese)
JP: (Japanese)
Remote ControllerYes
BatteryYes (AAA x2)
Power CordYes
